Description
AXIS Q1809-LE 150 mm fixed bullet camera - 4/3" image sensor, robust outdoor, NEMA 4X, IP66, IP67 and IK10-rated 41 MP/ 8K resolution, day/night, fixed bullet camera with Deep Learning Processing Unit (DLPU). Support WDR, Lightfinder 2.0 and OptimizedIR, a power-efficient 850 nm technology. Varifocal 50 150 mm, 3 x optical Canon zoom lens, 21 degrees - 7 degrees HFOV with remote zoom and autofocus. Multiple, individually configurable H.264, H.265 with Zipstream and Motion JPEG. 8K up to 30 fps and 41MP at 15 fps. Video motion detection, shock detection and active tampering alarm. AXIS Edge Vault with FIPS 140-3 Level 3 for added cyber security. Defogging, electronic imaging stabilization and scene profiles. Audio in and supervised I/O port, microSD memory card slot for local storage. MQTT Support. Integrated bracket for easy mounting on wall and ceiling. Operation in -40C to + 55C (-40F to 131F). Powered by PoE class 4/6 (IEEE 802-3at), 20-28 V DC or 20-24 V AC. Includes a removable sunshield, IP66, IP67- rated cable glands and optional IDC punch connectors. 30W PoE out to power an additional device, requires 60 W midspan, IEEE 802.3bt Type 3 Class 6. Power supply or midspan not included.
| Manufacturer | Axis Communications |
|---|---|
| Part Number | 03019-001 |
| Product Type | Fixed cameras |
| Form Factor | Bullet |
| Effective Camera Resolution | 41MP |
| Maximum Video Resolution | 7424 x 5568 |
| Lens Type | Varifocal |
| Focal Length | 50-150mm |
| Indoor/Outdoor | Outdoor |
| Ingress Protection Rating | IP66, IP67 |
| Impact Protection Rating | IK08, IK10 |
| PoE | Yes |
| Input Voltage | 10-28V DC, 20-24V AC |
| Color | White |
| Height | 7.2" |
| Limited Warranty | 5-Year |
| Maximum Resolution | 1280 x 720 |
| Maximum Focal Length | 150.0mm |
| Minimum Focal Length | 5.0mm |
| Power over Ethernet (PoE) | Yes |
| Wide Dynamic Range | Yes |
| Image Sensor Type | CMOS |
| Certifications | CISPR 32 Class A, CISPR 35, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES(A)/NMB(A), IEC 62236-4, KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Certifications & Standards | ONVIF G, ONVIF M, ONVIF S, ONVIF T |
| Image Sensor Size | 4/3" |
| Number of Sensors | 1 |
| Maximum Operating Temperature | 131°F |
| Minimum Operating Temperature | 4°F |
| Operating Humidity | 10-100% |
| Operating Temperature (T-T) | -40-55°C |
| Longest Shutter Speed | 2 s |
| Minimum Illumination | 0.04lux |
| Shortest Shutter Speed | 1/10500 Second |
| Package Type | Box |
| Product Line | Q |
| Product Series | Q18 |
| Supported Network Protocols | IPv6 |
| Lens Included | Yes |
| Memory Card Supported | Yes |
| SD Card Slot | Yes |
| Environmental Certification | EU RoHS, REACH, RoHS |
| Environmentally Friendly | Yes |
| Features | Built-in cybersecurity with Axis Edge Vault, High light-sensitive 4/3" sensor, Out-of-the-box and outdoor-ready, Superior image quality in 8K, Wide or tele Canon lens |
| Package Contents | Camera, Extra cable gasket, Extra screw gaskets, Installation Guide, Owner authentication key, RJ45 Cable |
| Remote Management | Yes |
| Durability | Impact Resistant |
| Maximum Power Consumption | 51W |
| Diameter | 4.5" |
| Model Number Replaces | 01118-001, 0963-001 |
| Recording Formats | H.264, H.265 / HEVC |
| Storage Type | SD Card |
| Aperture | f/4.0 |
| Field of View | Horizontal, Vertical |
| Maximum Frame Rate | 30fps |
| Night Vision | Yes |
| Night Vision Type | Infrared (IR) |
| Optical Zoom | 3x |
| Video Formats | H.264 / AVC, H.265 / HEVC, MJPEG |
| Category | Physical Security > Video Surveillance > Surveillance Cameras |
| Shipping Weight | 0.31 lb |
| Country of Origin | PL |
